Viair Complete On-Board Air System Fast Fill - 380C + 2 Gallon Tank

Fast-Fill 200 PSI Air Source Kits come with a powerful, low amp-draw 380C VIAIR compressor mounted on a 200 PSI-rated 2.0 gallon air tank with 5 ports. All 200 PSI Air Source kits come with a pre-wired 165/200 PSI pressure switch. Both kits not only come with the industry’s leading 200 PSI compressors but also come with a drain cock, safety valve, 1/2-inch port compression fitting for 3/8? (I.D.) air line pre-installed! To use, simply connect the pressure switch to fused power, make a solid ground, and connect an air line to the compression fitting. A 40-amp relay and an appropriately-rated fuse is recommended for use with this unit.


– 12-Volt
– Permanent Magnetic Motor
– Duty Cycle: 100% @ 100 PSI (55% @ 200 PSI)
– Max. Working Pressure: 200 PSI
– Max. Amp Draw: 23 Amps
– Ingress Protection Rating: IP67
– Dimensions: 19?L x 5.9?W x 14.2?H
– Net Weight: 21.05 lbs.
– 380C Pewter Air Compressor
– 2.0 Gallon Air Tank
– Pressure Switch (165 PSI On / 200 PSI Off)
– Safety Valve (250 PSI)
– Drain Cock
– Leader Hose with Check Valve
