Viair Complete Onboard Air System Medium Duty - 150 PSI 2.5 Gallon Tank

VIAIR's Medium Duty Onboard Air System is a pre-packaged compressed air solution that provides a 33% duty cycle 325C compressor, 2.5 gallon air tank, and all components needed to install basic vehicle-based pneumatics.

The Medium Duty Onboard Air System comes complete with a dependable, low amp draw 325C, 33% Duty Cycle compressor at its heart that will fill the supplied 2.5 gallon tank from 110-150 PSI in approximately one minute.

Included is everything youll need to add a reliable single air source to your vehicle. (For vehicles with up to 33-inch tires).

(1) 2.5 Gallon VIAIR Air Tank
(1) 325C model VIAIR compressor(1) 1/4 NPT Quick Connect Coupler (1) Dash Panel Gauge with ON/OFF Switch
(1) Pressure Switch with Relay (110 PSI on, 150 PSI off)
(1) Reducer (1/8 NPT F to 1/4 NPT M)
(1) 1/4 NPT 175 PSI Safety Valve (1) 1/4 NPT Drain Cock
(1) 1/4 NPT Compression Fittings
(1) 4-inch Strip of Continuous Grommet Material
(1) 20-ft. 12 Gauge Wire with Inline Fuse holderp- 12-Volt
- Permanent Magnetic Motor
- Duty Cycle: 33% @ 100 PSI
- Max. Working Pressure: 150 PSI
- Max. Amp Draw: 21 Amps
- Ingress Protection Rating: IP67
